MOD. BEZZERA MODA PM – DE – DE+D – DE+D+M
3 - DESCRIPTION OF MACHINE
3.1 Description of operating cycle
The water arriving from the mains through a mo-
tor pump, adjusted to a pressure between 9 and
10 bar (0.9 - 1 MPa), passes through a pressure
relief valve, adjusted to 12 bar (1.2 MPa), allow-
ing both the boiler and the heat exchanger to be
filled. The water in the boiler, heated by a heat-
ing element, in turn heats the water in the heat
exchanger, which, thanks to a drip riser, is sent to
the group in order to brew the coffee by means of
an electronically controlled valve.
3.2 Description of controls (Fig. 01-
Fig. 08)
1 Steam valve
2 Hot water valve
3 Coffee dispensing button (4-key version:
steam or hot water)
4 Steam wand
5 Boiler heating activation indicator
6 Boiler drain plug
7 Filter holder
8 TFT touch screen display
9 Machine power switch
10 Pump and boiler pressure gauge
11 Blind filter
12 1-cup filter
13 2-cup filter
14 Boiler water level indicator
3.2.1 Description of control panels
(Fig. 06)
A . Coffee pre-selection key
B. Double coffee pre-selection key
C. Continuous dispensing-programming key
D. Tea - steam key
3.3 Technical data (Fig. 02)
The MODA PM-DE – DE+D espresso coffee ma-
chine is built in versions with 1 to 3 groups.
The 2-group version is described in this booklet;
however, the instructions for use and the layout of
the controls are the same for the other versions.
The A-weighted sound pressure level of the coffee
machine is less than 70dB.
Moda PM Moda DE Moda DE+D
1 Group 1 Group 1 Group
Power supply V-/Hz 230 230 230
Heating element W 2025 2025 2025
Nominal power W 2300 2300 2300
Width “A” mm 570 570 960
Depth “B” mm 550 550 550
Height “C” mm 515 515 515
Net weight Kg 45 45 45
Gross weight (pallets) Kg 54 54 54
Water input connector
G 3/8”
Drain connector
Moda PM Moda DE Moda DE+D
2 Groups 2 Groups 2 Groups
Power supply V-/Hz 230-400 230-400 230-400
Heating element W 5020 5020 5020
Nominal power W 5500 5500 5500
Width “A” mm 750 750 750
Depth “B” mm 550 550 550
Height “C” mm 515 515 515
Net weight Kg 59 59 59
Gross weight (pallets) Kg 70 70 70
Water input connector
G 3/8”
Drain connector
