4 - MACHINE INSTALLATION
4.1 Warnings
Installation must be carried out by qualified per-
sonnel, according to the instructions supplied by
the manufacturer and in compliance with current
laws.
The machine must be positioned and installed
in a place where use and maintenance are per-
formed exclusively by qualified personnel. The
machine can be used in places set up for staff
kitchen areas in shops, offices and other working
environments; holiday farm houses; by clients in
hotels, motels and other types of accommoda-
tion; bed and breakfast settings; etc.
4.2 Preparation of system for
installation
Place the machine on a flat, horizontal, even, dry,
smooth, sturdy, stable surface positioned at such
a height that the cup warming surface is over 150
cm from the ground. Do not use water jets or in-
stall in places where water jets are used.
To ensure normal operation, the appliance must
be installed in places where the temperature is
between +5°C and +32°C and the humidity
does not exceed 70%.
If the machine is exposed to temperatures below
+ 0°C, proceed as follows:
- ensure that the machine has spent 24 hours
in a location where the temperature is above
+15°C before switching it on.
The machine is electrically powered and requires
the following for its operation:
- connection to mains electricity.
- connection to mains water.
- connection to drainage circuit.
4.2.1 Connection to mains electricity
Warnings:
- The connection to the mains must be made by
qualified personnel.
- The wiring must be done in compliance with
current laws and earthed.
The machine is supplied with a power cord with-
out a plug; for a permanent electrical connection
between the appliance and the mains electric-
ity, fit a safety omnipolar switch with a minimum
opening between the contacts of overvoltage cat-
egory III, suitably sized for the load and in compli-
ance with the current regulations in force.
4.2.2 Connection to mains water
(Fig. 03)
Make sure that the water supply line is connected
to a drinking water network with operating pres-
sure between 0 and 6 bar (0 - 0.6 MPa).
If the water network has pressures above 6 bar
(0,6 MPa), install a pressure reducer.
Install a water shut-off valve upstream of the ma-
chine’s connection.
The water inlet pipe (Fig. 03; pos. 1) has a G
3/8” thread.
Warning:
Do not open the screw-on cap and
boiler exhaust valve: risk of scalding.
Use only the new inlet pipe supplied.
Moda PM Moda DE Moda DE+D
3 Groups 3 Groups 3 Groups
Power supply V-/Hz 230-400 230-400 230-400
Heating element W 5020 5020 5020
Nominal power W 5600 5600 5600
Width “A” mm 960 960 960
Depth “B” mm 550 550 550
Height “C” mm 515 515 515
Net weight Kg 74 74 74
Gross weight (pallets) Kg 86 86 86
Water input connector
G 3/8”
Drain connector
To Next Page
