BIFFI RPS User Manual

18
PARTS LIST - RPS S2-A1/B1/C1
Item Qty Description Material
1 1 Housing Nodular cast iron
2 1 Pinion Nodular cast iron
3 1 Piston Carbon steel
4 1 End flange Carbon steel
5 1 Rack Nodular cast iron
6 1 Shaft Alloy steel
7* 2 Cylinder gasket NBR
8* 2 Shoulder washer Nylon
9 2 Lifting eyelet Carbon steel
10 2 Nut Carbon steel
11 1 Spring retainer disk Carbon steel
12 1 Rack spacer rod Carbon steel
13 1 Cylinder tube Nickel plated carbon steel
14 4 Tie rod Alloy steel
15 1 Thrust bearing screw Alloy steel
16 1 Spring Alloy steel
17* 2 Sealing washer PVC
18* 1 Sealing washer PVC
19 1 Sliding block Bronze
20* 1 Piston guide sliding ring PTFE + graphite
21* 2 Retainer ring Spring steel
22 1 Screw Alloy steel
23* 2 O-ring NBR
24* 1 O-ring NBR
25 8 Nut Carbon steel
26 1 Nut Carbon steel
27 1 Washer Carbon steel
28 2 Washer Carbon steel
29 4 Spring pin Carbon steel
30 2 Travel stop screw Carbon steel
31 1 Screw Alloy steel
32 1 Plug Aluminium + bronze + steel
36 1 Spacer tube Carbon steel
* Recommended spare parts
RPS SPRING RETURN PNEUMATIC ACTUATOR
INSTALLATION, OPERATION AND MAINTENANCE MANUAL
