BIFFI RPS - Figure 4

5
A
B
A
A
A
RPS SPRING RETURN PNEUMATIC ACTUATOR
INSTALLATION, OPERATION AND MAINTENANCE MANUAL
BACK SIDE VIEW
Lifting eyelets (horizontal stem valve mounting position)
Lifting point to balance weight (suitable for slings)
(horizontal stem valve mounting position)
FIGURE 4
A = Lifting eyelets
B = Lifting point (balancing)
FRONT VIEW SIDE VIEW
TOP VIEW
Lifting eyelets suitable for vertical stem
valve mounting position (standard)
Lifting eyelets (standard position)
