BL-M22EP-0119 - 01-11-2019 9-5
CASTER ASSEMBLY
Pos. Part Number Description
Qty.
Reqd.
Notes
-- 2010-130000-00 CASTER ASSEMBLY 1
There are two Caster
Assemblies on the truck.
1 2010-131000-00 WHEEL BRACKET 1
2 2010-120001-00 SHAFT 1
3 0000-000077-00 SCREW M6×12 4
4 0000-000056-00 LOCK WASHER Ø6 4
5 0000-000437-00 FLAT WASHER Ø6 1
6 0000-000019-00 BEARING 2
7 2010-120003-00 NYLON WHEEL 1
8 2010-122000-00 PLATE 1
9 0000-000380-00 FLAT WASHER Ø6 3
To Next Page
