ELEVATION SYSTEM - TELESCOPIC
Pos. Part Number Description
Qty.
Reqd.
Notes
1 0000-000761-00 SCREW M12×20 4
2 2108-600002-60 BOLT 2
3 0000-000757-00 NUT M20X1.5 2
4 2108-600003-60 SPRING 2
5 2108-600004-60 POSITIONING ROD 2
6 2108-600005-60 CHAIN ROLLER Ø84 / Ø52X33 2
7 0000-000100-00 BEARING 2
8 0000-000294-00 RETAINER RING Ø25 4
9 0000-000758-00 ELASTIC COLLAR Φ52 2
10 0000-000374-00 SCREW M12×30 1
11 0000-000060-00 LOCK WASHER Ø12 2
12 0000-000373-00 FLAT WASHER Ø12 2
13 0000-000075-00 SCREW M12×30 1
14 2108-632000-70 ROLLER ASSEMBLY 2 Incl. Pos. # 32-36
15 2108-410000-60-04 LIFT CYLINDER 1 Lift Height 96” (2440mm)
15a 2108-410000-60-02 LIFT CYLINDER 1 Lift Height 116” (2945mm)
16 2010-620000-00 INNER MAST 1
17 0000-001525-00 SCREW M12×10 4
18 0000-000777-00 STEEL BALL 12.0000 G100 B 2
19 2108-600008-60 ROLLER SHELL Ø72X30 2
19a 0000-000759-00 BEARING 2
20 2108-600009-60 BEARING BLOCK 2
21 0000-000007-00 FLAT WASHER Ø10 6
22 0000-000063-00 LOCK WASHER Ø10 6
23 0000-000760-00 BOLT M10×30 6
24 2108-600011-60
CYLINDER HOLDER 1
25 0000-000166-00 NUT M6 4
26 0000-000056-00
LOCK WASHER Ø6 2
27 0000-000380-00 FLAT WASHER Ø6 2
28 0000-000109-00
SCREW M8×16 2
29 0000-000159-00
LOCK WASHER Ø8 2
30 0000-000176-00
FLAT WASHER Ø8 2
31 2316-600002-0B BRACKET 1
32 0000-001525-00 SCREW M12×10 2
33 0000-000761-00 SCREW M12×20 2
34 2108-650000-60 ROLLER 2
35 0000-000434-00 SNAP RING Ø30 2
36 2108-600012-60 CAP 2
To Next Page
