ELEVATION SYSTEM - SINGLE STAGE
Pos. Part Number Description
Qty.
Reqd.
Notes
1 0000-000756-00 RETAINER RING Ø40 2
2 2108-600001-00 SHAFT 1
3 2108-600003-00 WASHER 2
4 2108-600002-00 CHAIN ROLLER 1
5 2108-620000-00 CHAIN BRACKET 1
6 0000-000374-00 SCREW M12×30 1
7 0000-000060-00 LOCK WASHER Ø12 1
8 0000-000373-00 FLAT WASHER Ø12 1
9 0000-000321-00 SCREW M8×20 4
10 2111-600001-20 CYLINDER BRACKET 1
11 2108-410000-60 LIFT CYLINDER 1 Lift Height 62” (1575mm)
12 0000-000159-00 LOCK WASHER Ø8 4
13 0000-000176-00 FLAT WASHER Ø8 4
