BL-M22EP-0119 - 01-11-2019 9-11
FORK CARRIAGE - SINGLE STAGE
Pos. Part Number Description
Qty.
Reqd.
Notes
1 0000-000284-00 BOLT M12×30 4
2 0000-000060-00 LOCK WASHER Ø12 4
3 0000-000373-00 FLAT WASHER Ø12 4
4 2125-632000-00 BLOCKING SHELF 1
5 2010-631000-20 FORK FRAME 1
6 2108-632000-70 ROLLER ASSEMBLY 4 Incl. Pos. # 9-13
7 2108-630001-10 FORK 2
8 2125-630001-10 FORK PIN KIT 2
9 0000-001525-00 SCREW M12×10 4
10 0000-000761-00 SCREW M12×20 4
11 2108-650000-60 ROLLER 4
12 0000-000434-00 SNAP RING Ø30 4
13 2108-600012-60 CAP 4
To Next Page
