BIGTREETECH CB1 User Manual

Shenzhen Big Tree Technology Co., Ltd.
BIGTREETECH
6 / 22
14
A connector_14
GND
15
A connector_15
LINK_LED
Ethernet LED
16
A connector_16
NC
17
A connector_17
SPD_LED
Ethernet LED
18
A connector_18
NC
19
A connector_19
NC
20
A connector_20
NC
21
A connector_21
SYS-LED
System work light
22
A connector_22
GND
23
A connector_23
GND
24
A connector_24
PC15
3.3V IO(CB1 V2.1 is 1.8v )
25
A connector_25
PC8
3.3V IO(CB1 V2.1 is 1.8v )
26
A connector_26
PC6
3.3V IO(CB1 V2.1 is 1.8v )
27
A connector_27
PH10
3.3V IO
28
A connector_28
NC
29
A connector_29
NC
30
A connector_30
PG6
3.3V IO
31
A connector_31
PG9
3.3V IO
32
A connector_32
GND
33
A connector_33
GND
34
A connector_34
NC
35
A connector_35
PG7
3.3V IO
36
A connector_36
NC
37
A connector_37
PG8
3.3V IO
38
A connector_38
PH6
3.3V IO
39
A connector_39
NC
3.3V IO
40
A connector_40
PH8
3.3V IO
41
A connector_41
NC
42
A connector_42
GND
43
A connector_43
GND
44
A connector_44
PH7
3.3V IO
45
A connector_45
PC9
3.3V IO(CB1 V2.1 is 1.8v )
46
A connector_46
PC10
3.3V IO(CB1 V2.1 is 1.8v )
47
A connector_47
PC11
3.3V IO(CB1 V2.1 is 1.8v )
48
A connector_48
PC12
3.3V IO(CB1 V2.1 is 1.8v )
49
A connector_49
PC13
3.3V IO(CB1 V2.1 is 1.8v )
50
A connector_50
PC14
3.3V IO(CB1 V2.1 is 1.8v )
51
A connector_51
SoC_RX
DEBUG UART
52
A connector_52
GND
53
A connector_53
GND
54
A connector_54
PC7
3.3V IO(CB1 V2.1 is 1.8v )
55
A connector_55
SoC_TX
DEBUG UART
56
A connector_56
NC
57
A connector_57
SDC0-CLK
SDCARD Clock signal
