BIGTREETECH CB1 User Manual

Shenzhen Big Tree Technology Co., Ltd.
BIGTREETECH
7 / 22
58
A connector_58
NC
59
A connector_59
GND
60
A connector_60
GND
61
A connector_61
SDC0-D3
SDCARD Data3 signal
62
A connector_62
SDC0-CMD
SDCARD CMD signal
63
A connector_63
SDC0-D0
SDCARD Data0 signal
64
A connector_64
PG11
3.3V IO
65
A connector_65
GND
66
A connector_66
GND
67
A connector_67
SDC0-D1
SDCARD Data1 signal
68
A connector_68
PG12
3.3V IO
69
A connector_69
SDC0-D2
SDCARD Data2 signal
70
A connector_70
PG13
3.3V IO
71
A connector_71
GND
72
A connector_72
PG14
3.3V IO
73
A connector_73
PG16
3.3V IO
74
A connector_74
GND
75
A connector_75
NC
76
A connector_76
SDC0-DET
SDCARD detect
77
A connector_77
VCC_5V
5V IN /2A
78
A connector_78
NC
79
A connector_79
VCC_5V
5V IN /2A
80
A connector_80
NC
81
A connector_81
VCC_5V
5V IN /2A
82
A connector_82
NC
83
A connector_83
VCC_5V
5V IN /2A
84
A connector_84
3V3
3.3V out /200mA
85
A connector_85
VCC_5V
5V IN /2A
86
A connector_86
3V3
3.3V out /200mA
87
A connector_87
VCC_5V
5V IN /2A
88
A connector_88
1V8
1.8V out /100mA
89
A connector_89
NC
90
A connector_90
1V8
1.8V out /100mA
91
A connector_91
NC
92
A connector_92
PWRON
Power switch (useless)
93
A connector_93
FEL
(useless)
94
A connector_94
NC
95
A connector_95
NC
96
A connector_96
NC
97
A connector_97
NC
98
A connector_98
GND
99
A connector_99
RECOVERY
Program download (useless)
100
A connector_100
AP-RESET
power reset (useless)
101
B connector_1
NC
