BIGTREETECH CB1 User Manual

Shenzhen Big Tree Technology Co., Ltd.
BIGTREETECH
8 / 22
102
B connector_2
NC
103
B connector_3
USB1-DM
HOST USB1
104
B connector_4
LINEOUTL
105
B connector_5
USB1-DP
HOST USB1
106
B connector_6
LINEOUTR
107
B connector_7
GND
108
B connector_8
GND
109
B connector_9
NC
110
B connector_10
NC
111
B connector_11
TV_OUT
CVBS OUT
112
B connector_12
NC
113
B connector_13
GND
114
B connector_14
GND
115
B connector_15
NC
116
B connector_16
NC
117
B connector_17
NC
118
B connector_18
NC
119
B connector_19
GND
120
B connector_20
GND
121
B connector_21
NC
122
B connector_22
NC
123
B connector_23
NC
124
B connector_24
NC
125
B connector_25
GND
126
B connector_26
GND
127
B connector_27
NC
128
B connector_28
USB3-DM
HOST USB3
129
B connector_29
NC
130
B connector_30
USB3-DP
HOST USB3
131
B connector_31
GND
132
B connector_32
GND
133
B connector_33
NC
134
B connector_34
USB2-DM
HOST USB2
135
B connector_35
NC
136
B connector_36
USB2-DP
HOST USB2
137
B connector_37
GND
138
B connector_38
GND
139
B connector_39
NC
140
B connector_40
USB0-DM
OTG USB
141
B connector_41
NC
142
B connector_42
USB0-DP
OTG USB
143
B connector_43
NC
144
B connector_44
GND
145
B connector_45
NC

BIGTREETECH CB1 Specifications

General

Brand	BIGTREETECH
Model	CB1
Category	Computer Hardware
Language	English
