BIGTREETECH CB1 User Manual

Shenzhen Big Tree Technology Co., Ltd.
BIGTREETECH
9 / 22
146
B connector_46
NC
147
B connector_47
NC
148
B connector_48
NC
149
B connector_49
NC
150
B connector_50
GND
151
B connector_51
HCEC
HDMI CEC
152
B connector_52
NC
153
B connector_53
HHPD
HDMI Hotplug
154
B connector_54
NC
155
B connector_55
GND
156
B connector_56
GND
157
B connector_57
NC
158
B connector_58
NC
159
B connector_59
NC
160
B connector_60
NC
161
B connector_61
GND
162
B connector_62
GND
163
B connector_63
NC
164
B connector_64
NC
165
B connector_65
NC
166
B connector_66
NC
167
B connector_67
GND
168
B connector_68
GND
169
B connector_69
NC
170
B connector_70
HTX2P
HDMI TX2 Positive.
171
B connector_71
NC
172
B connector_72
HTX2N
HDMI TX2 Negative.
173
B connector_73
GND
174
B connector_74
GND
175
B connector_75
NC
176
B connector_76
HTX1P
HDMI TX1 Positive.
177
B connector_77
NC
178
B connector_78
HTX1N
HDMI TX1 Negative.
179
B connector_79
GND
180
B connector_80
GND
181
B connector_81
NC
182
B connector_82
HTX0P
HDMI TX0 Positive.
183
B connector_83
NC
184
B connector_84
HTX0N
HDMI TX0 Negative.
185
B connector_85
GND
186
B connector_86
GND
187
B connector_87
NC
188
B connector_88
HTXCP
HDMI CLK Positive.
189
B connector_89
NC
