121
5.3.9.6 IGMP
IGMP, known as Internet Group Management Protocol, is used to management hosts from
multicast group.
IGMP Proxy: Accepting multicast packet. Default is set to Disable.
IGMP Snooping: Allowing switched Ethernet / Wireless to check and make correct
forwarding decisions. Default is set to Disable.
5.3.9.7 SNMP Access Control
Software on a PC within the LAN is required in order to utilize this function – Simple Network
Management Protocol.
SNMP V1 and V2:
Read Community: Specify a name to be identified as the Read Community, and an IP
address. This community string will be checked against the string entered in the
configuration file. Once the string name is matched, user obtains this IP address will be able
to view the data.
Write Community: Specify a name to be identified as the Write Community, and an IP
address. This community string will be checked against the string entered in the
To Next Page
