2.3 Lateral control panel, left side (KBF P, option KBF)
(10) (11)
(14)
(15)
Figure 7: Lateral control panel KBF (option) / KBF P at the left side of the humidity module
with option temperature safety device class 3.3
(10) Switch for ICH compliant illumination cool white (KBF P)
(11) Switch for ICH compliant illumination BINDER Q1B Synergy Light (UVA + cool white) (KBF P)
(12) Not used
(13) Not used
(14) Temperature safety device class 3.1 (part of option safety device class 3.3)
(15) Temperature safety device class 3.2 (part of option safety device class 3.3)
