3. Completeness of delivery, transportation, storage, and installation
3.1 Scope of delivery
• Pump with small flange connection DN 16 KF
• 2 condensate catchpots (glass flasks), packed separately
2 fork clamps (conical ground clamps) for condensate catchpots
Pneumatic connection (PTFE tube with 2 angle adjustment screws)
• Emission condenser with insulation, packed separately
2 fastening straps for emission condenser
• Hose nozzle DN 8
• Power cable with IEC connector plug
• Operating manual
3.2 Unpacking, and checking the equipment
Carefully unpack the vacuum pump VAP 1 / VAP 2.
After unpacking, please check the device and its optional accessories, if any, based on the delivery
receipt for completeness and for transportation damage. Inform the carrier immediately if transportation
damage has occurred.
The final tests of the manufacturer may have caused traces of the shelves on the inner surfaces. This has
no impact on the function and performance of the device.
Please remove any transportation protection devices and adhesives on the device and remove the
operating manuals and accessory equipment.
Remove the protective caps on the suction and pressure connections:
Dust protective cap for small flange connection
DN 16 KF (suction side)
Protective sleeve for hose nozzle
(pressure side)
Figure 5: Protective caps on the suction and pressure connections
If you need to return the device, please use the original packing and observe the guidelines for safe lifting
and transportation (chap. 3.4).
For disposal of the transport packing, see chap. 9.1.
