Binder VAP 1 - Electrical Connection

VAP 1 / VAP 2 06/2020 Page 23/52
4.2 Electrical connection
The devices are supplied ready for connection. They come with an IEC connector plug.
Model Art. No. Power plug
Voltage +/-10% at the
indicated power
frequency
Current type
Vacuum pump
VAP 1
5013-0217 Grounded plug
200-230 V at 50 Hz
200-230 V at 60 Hz
1N~
Vacuum pump
VAP 1
5013-0223 NEMA 5-15P
200-240 V at 50Hz
200-240 V at 60Hz
2~
Vacuum pump
VAP 2
5013-0218 Grounded plug
200-230 V at 50 Hz
200-230 V at 60 Hz
1N~
Vacuum pump
VAP 2
5013-0219 NEMA 5-15P
200-240 V at 50Hz
200-240 V at 60Hz
2~
Please note when connecting to the Power supply:
• The electrical network must provide a protective conductor in accordance with IEC 60364-4-41.
• The protective conductor must not have any interruptions.
• The domestic socket must also provide a protective conductor. Make sure that the connection of the
protective conductor of the domestic installations to the device’s protective conductor meets the latest
technology. The protective conductors of the socket and plug must be compatible!
DANGER
Electrical hazard due to missing protective conductor connection.
Deadly electric shock
 Make sure that the device
’s power plug and the power socket match and securely
connect the electrical protective conductors of the device
and the house
installation.
• Prior to connection and start-up, check the power supply voltage. Compare the values to the specified
data located on the device’s type plate (left device side, bottom right-hand, see chap. 1.6). We
recommend the use of a residual current circuit breaker.
NOTICE
Danger of incorrect power supply voltage due to improper connection.
Damage to the device.
 Check the power supply voltage before connection and start-up.
 Compare the power supply voltage with the data indicated on the type plate.
• When connecting, please observe the regulations specified by the local electricity supply company as
well as the VDE directives (for Germany).
• Only use original connection cables from BINDER according to the above specification.
• Make sure that the connection cable is NOT damaged.
• Pollution degree (acc. to IEC 61010-1): 2
• Over-voltage category (acc. to IEC 61010-1): II
See also electrical data (chap. 10.1).
