VAP 1 / VAP 2 06/2020 Page 34/52
• Place the pump in a way that the form diaphragm (9) is horizontal.
• Screw the form diaphragm (9) tight.
• Bring the connecting rod and the form diaphragm (9) into the middle position
• Put on the pump head (5).
• Insert the valves (7), the valve inserts (6), and the O-rings (8). Pay attention to full-surface contact! Do
not insert the ridge side towards the sealing surface.
NOTICE
Danger of leaks due to improper assembly.
Final pressure is not reached.
Make sure that the components are correctly inserted.
• Put on the heat dissipater (4) and tighten the four cylinder screws (3) symmetrically with a torque of 3 -
4 Nm
• Reconnect the hose connections (2) with the compression fitting (1).
8.4.2 Function test
• Connect a vacuum measuring device to the suction connection of the pump and measure the final
pressure. If it functions properly, this must correspond to the technical data after a maximum of one
minute.
• The pump must not generate any abnormal noises.
• Moving parts must not touch each other.
8.5 Sending the device back to BINDER GmbH
If you return a BINDER product to us for repair or any other reason, we will only accept the product upon
presentation of an authorization number (RMA number) that has previously been issued to you. An
authorization number will be issued after receiving your complaint either in writing or by telephone prior
to your sending the BINDER product back to us. The authorization number will be issued following receipt
of the information below:
• BINDER product type and serial number
• Date of purchase
• Name and address of the dealer from which you bought the BINDER product
• Exact description of the defect or fault
• Complete address, contact person and availability of that person
• Exact location of the BINDER product in your facility
• A contamination clearance certificate (chap. 13) must be faxed in advance
The authorization number must be applied to the packaging in such a way that it can be easily recognized
or be recorded clearly in the delivery documents.
For security reasons we cannot accept a device delivery if it does not carry an authorization
number.
BINDER GmbH
Abteilung Service
Gänsäcker 16
78502 Tuttlingen, Germany
