1.5 Localization / position of safety labels on the chamber
The following labels are located on the chamber:
Pictograms (Warning signs)
Figure 1: Position of labels on the chamber (example:
regular chamber with RD4 controller)
Hot surface
(on the outer chamber door)
Service label
Keep safety labels complete and
legible.
Replace safety labels that are no longer
legible. Contact BINDER Service for these
replacements.
1.6 Type plate
The type plate sticks to the left side of the chamber, bottom right-hand.
Figure 2: Type plate (example of VD 115)
Indications of the type plate (example)
Information
BINDER
Manufacturer: BINDER GmbH
VD 115
Model designation
Vacuum Drying Oven
Device name
Serial No.
000000000000
Serial no. of the chamber
Built
2020
Year of construction
Nominal temperature
220 °C
428 °F
Nominal temperature
IP protection
20
IP type of protection acc. to standard EN 60529
Nominal temp.
220 °C
1,60 kW / 7,0 A
428 °F
230 V / 50 Hz
IP protection
20
230 V / 60 Hz
Safety device
DIN 12880
1 N ~
Class
2.0
Art. No.
9630-0003
Project No.
Built
2020
Vacuum Drying Oven
BINDER GmbH
Im Mittleren Ösch 5
78532 Tuttlingen / Germany
www.binder-world.com
VD 115
E3.1
Serial No. 00000000000000
Made in Germany
