Binder VD 56 - 2.2 Instrument panel with regular RD4 controller; 2.3 Instrument panel with optional MB2 controller; 2.4 Connections on the rear of the chamber

VD (E3.1) 03/2020 page 21/173
2.2 Instrument panel with regular RD4 controller
RD4 controller display
USB interface
Figure 5: Instrument panel with RD4 controller and USB interface
2.3 Instrument panel with optional MB2 controller
5,7" controller display with touchscreen
USB interface
Pilot lamp
Figure 6: Instrument panel with MB2 program controller and USB interface
2.4 Connections on the rear of the chamber
Rear control panel
(1a) Strain relief for IEC connector plug
(12) Measuring connection with small flange
DN16
Figure 7: Chamber rear (example: VD 115)
