1) Handle bars:
Place bushing on the handle bar tube and twist to
get a tight seal.
Insert the handle bar stem into the tube.
Confirm that it does not go past the indicator.
Ensure the handle bar lines up with the forks.
Tighten all bolt with the 5 and 6 mm allen
wrenches
2) Wheel:
Remove acorn bolts and washers from the end of
the forks.
Insert the wheel between the forks ensuring the
break disk is on the left lining up with the break
caliper.
Replace acorn bolts and washers-tighten.
Remove bolts with 4mm allen wrench.
Make sure you remove the bolt completely so
you can place the headlight through the front of
the bolt before you slide the fender through from
behind.
Slide the fender through and tighten bolts.
3) Pedals:
There will be left and right indicators on the
pedal stems.
Use the 15 mm wrench to tighten.
The left pedal will be reverse thread so you will
tighten it counter-clockwise.
4) Seat:
Insert the tapered end of the seat rod into the
body of the bike.
Lock the seat in place at the appropriate height
ensuring it is past the minimum insertion line.
Attach the rear reflector to the seat stem using
the provided rubber strips.
5) Water bottle:
Mount bracket to frame using the bolts that are
already in the frame. Use 4mm allen wrench to
tighten down.
1) Handle bars:
Remove front plate of the handle bar bracket.
Place handle bars in mount ensuring they are
centered.
Replace front place and tighten bolts with 4mm allen
wrench.
2) Wheel:
Remove acorn bolts and washers from the end of the
forks.
Insert the wheel between the forks ensuring the
break disk is on the left lining up with the break
caliper.
Replace acorn bolts and washers-tighten.
Remove bolts with 4mm allen wrench.
Make sure you remove the bolt completely so you can
place the headlight through the front of the bolt
before you slide the fender through from behind.
Slide the fender through and tighten bolts.
3) Front Break adjustment:
Loosen left allen bolt of front break assembly.
Pull and tighten break cable so it is just off the tire.
That way when you engage the break it touches the
tire. Tighten allen bolt back down.
5) Pedals:
There will be left and right indicators on the pedal
stems.
Use the 15mm wrench to tighten.
The left pedal will be reverse thread so you will
tighten it counter-clockwise.
6) Seat:
Insert the tapered end of the seat rod into the body of
the bike.
Lock the seat in place at the appropriate height
ensuring it is past the minimum insertion line.
7) Water bottle:
Mount bracket to frame using the bolts that are
already in the frame. Use 4mm allen wrench to
tighten down.
1) Unfold and latch into
place.
2) Lock safety latch.
3) Put kick stand down to
stabilize bike if not using a
stand.
4) Make sure wheel is facing
left.
5) Match up the grooves on
the handle bar stem, slide
into handle bar tube, and
lock down.
6) Work your way from the
front to the back of the
bike making sure
everything is tight and
locked into place.
7) Pedals:
Left and right indicators
will be on the pedal stem.
Use 15 mm wrench to
tighten.
Left pedal is reverse
thread.
8) Water bottle:
Mount bracket to frame
using the bolts that are
already in the frame.
Use 4mm allen wrench to
tighten down.
4) Handle bars:
Remove front plate of the handle bar
bracket.
Place handle bars in mount ensuring
they are centered.
Replace front place and tighten bolts
with 4mm allen wrench.
5) Wheel:
Remove locking bolt from the front
wheel.
Insert the wheel between the forks
ensuring the break disk is on the left
lining up with the break caliper.
Insert the quick release hub through
the hole. Use the spring and bolt to
lock it in place. Ensure the quick
release hub is locked down.
Rotate head light and tighten it down
with 4 mm allen wrench.
6) Pedals:
There will be left and right indicators
on the pedal stems.
Use the 15 mm wrench to tighten.
The left pedal will be reverse thread
so you will tighten it counter-
clockwise.
7) Seat:
Insert the tapered end of the seat rod
into the body of the bike.
Lock the seat in place at the
appropriate height ensuring it is past
the minimum insertion line.
8) Water bottle:
Mount bracket to frame using the
bolts that are already in the frame.
Use 4mm allen wrench to tighten
down.
