biochrom Anthos Fluido 2 - Center Position Entry; Center Position Teach-in mode; Crosswise Aspiration Selection

Biochrom Anthos Fluido-2 Microplate Washer v2.0 Page 56
 Function keys:
<F1> or <F2>
Select "Esc" to return to the main menu without saving any changes.
Select “Mov” to position the plate to the current center position and
switch to the “teach-in” mode.
<+> or <->
Use these keys to enter the center position The plate can be moved in
steps of 0.1mm (range: -5.0 – 5.0mm).
<enter>
Confirm the center position and go to the next screen.
Screen
61.
Center Position “Teach-in” mode
In this „teach-in‟ mode the round-bottom plate can be moved to the correct
center position by using <+> or <->.
 Function keys:
<F1> or <F2>
Select "" to automatically detect the bottom of the well (changes to
“”).
Select "" to move the manifold up.
Select “Mov” to move the plate transport to the current center position.
<+> or <->
Use these keys to enter the center position. The plate can be moved in
steps of 0.1mm (range: -5.0 – 5.0mm).
<enter>
Confirm the center position and go to the next screen.
Screen
62.
Crosswise Aspiration Selection
If a flat-bottom plate is selected this menu appears. When using crosswise
aspiration the aspiration needle is first moved close to one wall of the well
(side pos front) and aspirates there. After the defined aspiration time the
needle is moved up to avoid scratching the bottom and is shifted to the
opposite wall (side pos rear). There the needle is moved down and another
aspiration sequence takes place. For a better aspiration result crosswise
Center pos:
 Mov 0.1 mm
<< Esc Yes
