Biochrom Anthos Fluido-2 Microplate Washer v2.0 Page 17
4.10 Re-packing to prevent damage during transport
The original Fluido 2 packing has been specially designed for this
equipment.
1. Remove the manifold and tubing and the plate carriage and pack them
into the accessories boxes.
2. Lock the holder of the manifold with the foam part as shown in picture
1.
3. Put the transport lock plate at the location shown in picture 2 and
secure the plate with adhesive tape.
4. Place the foam parts left and right on the washer and put the washer
into the transport box. (picture 3).
5. Place the the bottles and the accessory boxes into the spaces left and
right of the instrument as shown on picture 3.
It is therefore recommended to save the original carton with its foam parts and
accessories box. Warranty claims are void if transport damages are caused by improper
packing!
picture 1 picture 2
picture 3
