Biochrom Anthos Fluido-2 Microplate Washer v2.0 Page 52
<enter>
Confirm the selection of the minimum soaking time. The set
parameters will be stored and the program returns to the main menu.
9.5 Define Plate Menu
The following drawings help to find the correct positions of the manifold
and plate. Please note that curved bottom plates do not allow crosswise
aspiration!
Dispense needle
Aspiration needle
Aspiration needle
Dispense needle
