biochrom Anthos Fluido 2 - Aspiration Height Position; Aspiration Height “Teach-in” mode

Biochrom Anthos Fluido-2 Microplate Washer v2.0 Page 61
<+> or <->
Use these keys to enter the side position rear. The plate can be moved
in steps of 0.1mm (range: -5.0 – 5.0mm).
<enter>
Confirm the side position rear and go to the next screen.
Screen
67.
Aspiration Height Position
The aspiration height position defines the height of the manifold during
aspirating a well. It may be defined by "teach-in" (move the manifold to
the correct position with the <+> and <-> keys).
 Function keys:
<F1> or <F2>
Select "Esc" to return to the main menu without saving any changes.
Select “Mov” to position the manifold to the current aspiration height
and switch to the “teach-in” mode.
<+> or <->
Use these keys to enter the aspiration height in steps of ~0.1mm
(range: 0 – 18.8mm).
<enter>
Confirm the aspiration height and go to the next screen.
Screen
68.
Aspiration Height “Teach-in” mode
In this special "teach-in" mode the manifold can be moved to the correct
height with the <+> and <-> keys. This mode features an automatic
bottom detection. For an optimal aspiration result move the aspiration
needle about 0.5mm up.
 Function keys:
<F1> or <F2>
Select "" to automatically detect the bottom of the well.
<+> or <->
Use these keys to move the manifold. The manifold can be moved in
steps of ~0.1mm (range: 0 – 18.8mm).
Aspiration ht:
Esc Mov 7.0 mm
Aspiration ht:
 0.1 mm
