Biometra TGRADIENT 48 - Appendix and Support Information; Technical Specifications; Ordering Information

TGRADIENT Manual __________________________________________________________ 31
13 Appendix
13.1 Technical specification TGradient 96
Thermal range -3°C – 100°C
Temperature accuracy + 0.1°C
Thermal homogeneity + 0.3°C within 15 sec.
Range of Gradient 40°C
Maximum heating speed 4°C/sec.
Max. cooling speed 3°C/sec.
Sample capacity 96 x 0.2ml tubes, 96 well microplates, strips
Line Voltage 115 Volt or 230 Volt
Frequency 50-60 Hz
Maximum power consumption 310 Watt
Fuses see label on the back of the instrument
Display LCD graphical display, back-lit
Ports serial: RS232 (bi-directional data transfer)
parallel: Centronics (printer)
Port for in tube-sensor
memory Total capacity: 1500 steps
in 10 directories with maximum 100 programs each
Dimensions (WxDxH) 25 x 34 x 16,5 cm
Weight 8,8 kg
Storage conditions
Operating conditions 5°C – 35°C
13.2 Ordering information
TGRADIENT Thermocycler
Order-No.
TGRADIENT 48 for 48 x 0.5ml tubes 050-800
TGRADIENT 96 for 96 x 0.2ml tubes, strips or 96 well microplates 050-801
TGRADIENT Modules
TGRADIENT 48 Module for 48 x 0.5ml tubes 050-810
TGRADIENT 96 Module for 96 x 0.2ml tubes, strips or 96 well microplates 050-811
TGRADIENT 384 Module for 384 well microplates (non gradient) 050-812
TGRADIENT in situ Module for 4 microscopic slides (non gradient) 050-813
For information about tubes, strips, microplates and other consumables please contact
BIOMETRA or your local BIOMETRA distributor.
