Medical Standard Definition : F-type applied part
(floating/insulated) complying with the specified requirements of
IEC 60601-1/UL 2601-1/CSA 601.1 Medical Standards to provide
a higher degree of protection against electric shock than that
provided by type B applied parts.
Equipotentiality
PAPER
RS-232
LAN
AUX CONNECTOR
DC INPUT INDICATOR
- +
BATTERY OPERATION INDICATOR
+-
DC 18V 2.5A
DC INPUT CONNECTOR
