BM3 www.BIO2NET.com
Revision A
- 33 -
Inspection standards
- Control the volume of the sound
- The alarm mode according the setting values & situation
Inspection procedure
- Check the volume level of the sound
- Check the alarm sound after changing the ECG HR
Electrical safety
Inspection contents
- Inspect the voltage
- Inspect the patient leakage current
Inspection standards
- Between the power teminals :1500Volt
- Between the power and ECG electrode : AC4000Volt
- Between the power and temp : AC4000Volt
- Patient leakage current should be under 50uA
Inspection procedure
- Check the insulation after giving the AC1500Volt during 60 sec.
between power teminals
- Check the insulation after giving the AC4000Volt during 60 sec.
between power teminals and terminals of the ECG electrode
- Check the insulation after giving the AC4000Volt during 60 sec.
between power teminals and the temp sensor
- Check the leakage current after connecting the all sensor
