Bionet BM3 - Ext. Board

BM3 www.BIO2NET.com
Revision A
- 26 -
CPLD
FIFO
MOTOR DRIVER
DATA BUS (FROM DIGITAL BOARD)
DATA BUS
MOTOR CONTROL
SIGNAL
+7.2V (FROM DIGITAL BOARD)
THERMAL PRINTER SIGNAL (TO
PRINTER)
MOTOR SIGNAL (TO MOTOR)
Ext. Board
Consists of the Speaker drive circuit, exterior serials and Dsync outputs
