Bionet BM3 - Battery and Power Troubleshooting

BM3 www.BIO2NET.com
Revision A
- 36 -
6. Failure in battery recharge (the battery does not fully recharge in 6 hours or more)
7. Power failure
The battery voltage
is lower than 5v
YES
NO
Replace the battery
Repair the power B/D
"Admit" has been
selected in the Menu
YES
NO
Execute the "Admit" function
(No data will be stored during battery
discharge)
The Digital B/D (dig)
Battery has lower than 3v
Repair the Dig B/D
NO
YES
Replace the battery (3volt)
The output voltage of the
adapter is 18v
YES
NO
Replace the adapter
(the battery will not be charged at the rate
lower than 17v)
YES
NO
Replace the adapter
Repair the power B/D
The adapter connector
is in bad conditions
YES
NO
Replace the adapter
The output voltage of the
adapter is lower than 18v
