Chapter 1 Motherboard Description
1-23
1.7 DRAM Installation
1.7.1 DIMM
DRAM Access Time : 3.3V Unbuffered SDRAM PC100 Type required.
DRAM Type : 8MB/16MB/32MB/64MB/128MB/256MB DIMM Module (168pin)
Total Bank 0 Bank 1
Memory Size (MB) DIMM1 DIMM2
8 M 8M x 1 pc ----
16 M 16M x 1 pc ----
32 M 32M x 1 pc ----
64 M 64M x 1 pc ----
128 M 128M x 1 pc ----
256 M 256M x 1 pc ----
16 M 8M x 1 pc 8M x 1 pc
32 M 16M x 1 pc 16M x 1 pc
64 M 32M x 1 pc 32M x 1 pc
128 M 64M x 1 pc 64M x 1 pc
256 M 128M x 1 pc 128M x 1 pc
512 M 256M x 1 pc 256M x 1 pc
*The list shown above for DRAM configuration is only for reference.
