Chapter 2 BIOS Setup
2-17
2.5 Integrated Peripherals
Figure 5. Integrated Peripherals
OnChip IDE Control
The chipset contains a PCI IDE interface with support for two IDE channels.
Select “Enabled” to activate the first and/or second IDE interface. Select
“Disabled” to deactivate an interface, if you install a primary and/or secondary
add-in IDE interface. If you highlight the literal “Press Enter” next to the “Onchip
IDE Control” label and then press the enter key, it will take you a submenu with
the following options:
OnChip IDE Channel 0
The chipset contains a PCI IDE interface with support for two IDE
channels. Select Enabled to activate the primary IDE interface. Select
Disabled to deactivate this interface.
The Choices: Enabled (default), Disabled.
OnChip IDE Channel 1
The chipset contains a PCI IDE interface with support for two IDE
channels. Select Enabled to activate the secondary IDE interface.
Select Disabled to deactivate this interface.
The Choices: Enabled (default), Disabled.
CMOS Setup Utility-Copyright (C) 1984-2000 Award Software
Integrated Peripherals
Item Help
Menu Level
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
OnChip IDE Control Press Enter
Muti-Media Setting Press Enter
Init Display First PCI Slot
IDE HDD Block Mode Enabled
Onboard FDD Controller Enabled
Onboard Serial Port 1 Auto
Onboard Ir Port Disabled
Onboard Parallel Port 378/IRQ7
Onboard Parallel Mode Normal
ECPModeuseDMA 3
Parallel Port EPP Type EPP1.9
X UART 2 Mode HPSIR
X IR Function Duplex Half
X TX, RX inverting enable No, Yes
