P4M900-M7 FE/P4M890-M7 FE
18
VGA Master 1 WS Read
When enabled, read to the AGP (Accelerated Graphics Port) are executed with
one wait states.
The Choices: Enabled (default), Disabled.
VGA Share Memory Size
This item allows you to select the VGA share memory size.
The Choices: 64M (default), 128M, 256M, Disabled
Direct Frame Buffer
This item allows you to disabled or enabled direct frame buffer
The Choices: Enabled (default), Disabled.
CPU & PCI Bus Control
By highlighting the “Press Enter” label next to the “CPU & PCI Bus Control”
and press the enter key, it will take you a submenu with the following options:
Figure 4.2: CP U & PCI Bus Co ntrol
PCI Master 0 WS Wr ite
When enabled, writes to the PCI bus are executed with zero-wait states.
The Choices: Enabled (default), Disabled.
To Next Page
