P4M900-M7 FE/P4M890-M7 FE
32
Reset Configuration Data
The system BIOS s upports the PnP feature whic h requires the system to reco rd
which resourc es are ass igned and pro tects resourc es from conflict.
Every peripheral device has a nod e, which is c alled ESCD. This node records
which resources are ass igned to it. The s ystem needs to record and update ESCD
to the memory loc ations. These loc ations are reserved in the system BIOS. If the
Disabled (default) option is chosen, the system‘s ESCD will update only when
the new configuration varies from the las t one. If the Enabled optio n is chosen,
the s ystem is forced to update ESCDs and then is automatically set to the
“Disabled” mode.
The above settings will be shown o n the screen o nly if “Manual” is chosen for
the resources contro lled by function.
Legacy is the term, which s ignifies that a resourc e is ass igned to the ISA Bus
and provid es non-PnP ISA add-o n c ards. PCI / ISA PnP signify that a resource
is assigned to the PCI Bus or provides for ISA PnP add-on cards and
peripherals.
The Choices: Disabled (default), Enabled.
Resources Controlled By
By Choos ing “Auto(ESCD)” (default), the system BIOS will detect the system
resources and automatically assign the relative IRQ and DMA channel for each
peripheral. By Choosing “Manual”, the user will need to assign IRQ & DMA for
add-on cards. Be sure that there are no IRQ/DMA and I/O port conflicts.
The Choices: Auto (ESCD) (default), Manual.
IRQ Resources
This s ubmenu will allow you to assign each s ystem interrupt a type, depending
on the type of device using the interrupt. When you press the “Press Enter” tag,
you will be directed to a submenu that will allow you to configure the system
interrupts. This is only configurable when “Resources Controlled By” is set to
“Manual”.
IRQ-3 assigned to PCI Device
IRQ-4 assigned to PCI Device
IRQ-5 assigned to PCI Device
IRQ-7 assigned to PCI Device
IRQ-9 assigned to PCI Device
IRQ-10 assigned to PCI Device
IRQ-11 assigned to PCI Device
IRQ-12 assigned to PCI Device
IRQ-14 assigned to PCI Device
IRQ-15 assigned to PCI Device
