BIRO EMG-32 - Safety Label Locations

32
EMG62050
Hopper weldment
EMG62092
SSS26
Set screw,
5
/16-18 x ½”
EMG82034
Spacer, inner bearing race
8
9
7
10
Item No.
Description
Fig.
Spur gear
EMG82032
Sealed bearing
EMG62015
EMG92032
Flat washer, .397 x 1¼ x .120 thk. SS
HHS070S
Hex screw ⅜ -16 x 1”, SS
12
13
11
14
Paddle shaft bearing mount
EMG62012
40B20F x 1¼” Sprocket
EMG20050-06
EMG20050-01
#40 Chain connecting link
EMG82029
40B36F x 1” bore sprocket
16
17
15
18
#40 Roller chain w/ master link
SSS26
Set screw,
5
/16 -18 x ½”
19
42MC-Y73
Start pushbutton, Green
50655-2
EMG90676
3 Position, Selector Switch, Paddle direction
EMG62039
Pushbutton legend, Front Cover, S/N: 6301 on
2
3
1
4
Item No.
DescriptionFig.
Switch guard, SS
42MC-Y74
Stop pushbutton, Red
EMG90668
Selector switch, Hand/Foot control
5
6
7
8
9
11
12
11
10
18
19
16
17
19
15
14
13
10
MIX GRIND
EMG-32
