BIRO F1000N - Page 23

20
CONVEYOR BELT DRIVE
DescriptionItem No.
F9308200
Ring UNI 7435
F93M0030
Pinion
F93M0032
Support, pinion
F93M0033
Drive shaft, conveyor
F93M0034
Support, conveyor drive shaft
F93M0036
Support, conveyor arm
F93M0037
Spacer, conveyor arm support
F93M0038
Drive roller, conveyor, 64 x 140
Fig No.
1
2
3
4
5
6
7
8
9
10
GG312
Key, 5 x 5 x 14, SS
GG388
Seal, 20-30-7-DL
11
12
GVT206
Hex head screw, M6-1.0 x 12, SS
DescriptionItem No.
GVT252
Hex head screw, M10-1.5 x 35, SS
GVT448
Set screw cone pt, M8-1.25 x 10, SS
GVT452
Set screw cone pt, M8-1.25 x 16, SS
GW8CUS
Bearing, 6003 2RS1
Fig No.
13
14
15
16
GVT022
Retaining ring, E17, SS
GW9CUS
Bearing, 6004 2RS1
17
1
2
3
4
5
6
7
8
9
10
11
13
12
14
15
16
17
