SB-170-10 27
295
SL DL
J
A
355
L
70
Ø35 (1 3/8'')
Ø21
70
D 793
1/4-18 NPTF
6 4 / 8
5/8-18 UNF
5
9
4 / 8
B
95
22520
450
520
F
30
16
7/16-20 UNF
1 (HP)
1/8-27 NPTF
2 (HP)
731
30
13
N
70
1/8-27 NPTF
3 (LP)
1 1/8-18 UNEF1/8-27 NPTF
12
1 1/8-18 UNEF
17
M26x1,5
(Adaptor connection:
Ø22 / 7/8'')
I
C
20
M10x20
Abb.15: Maßzeichnung CSW9563-140Y .. CSW95113-320(Y), CSH9663-160Y .. CSH96113-320Y
A
mm
B
mm
C
mm
D
mm
F
mm
I
mm
J
mm
L
mm
N
mm
CSW9563, CSW9573,
CSH9663, CSH9673
1824 717 776 224 417 41 930 751 118
CSW9583, CSW9593,
CSH9683, CSH9693
1842 717 776 242 417 34 948 751 122
CSW95103-240Y 1927 731 796 242 431 26 948 751 120
CSW95103-280(Y),
CSW95113-280Y,
CSH96103-280Y
1955 731 796 269 431 26 975 751 120
CSW95113-320(Y),
CSH96113-320Y
1974 731 796 289 431 26 994 751 120
