BIXOLON SRP-350plusV User Manual

Network Connection Manual
Ver.1.00
- 10 -
If the above message is printed, select Mode 1 / 3, and you will see the following LAN
data.
- To select Mode 1, press the Feed button once quickly/ once long.
- To select Mode 3, press the Feed button three times quickly/ once long.
<LAN 정보 출력>
<WLAN Information Printing >
LAN SETTING
MAC ADDRESS : 00:15:94:C2:6B:A8
IP ADDRESS : 192.168.0.48
SUBNET MASK : 255.255.255.0
GATEWAY : 192.168.0.1
PORT : 9100
INACT. TIME : 0
WLAN SETTING
WLAN F/W VERSION : 02.00(3930)
SYSTEM NAME : SRP-350plusV
NETWORK MODE : SOFT AP
FREQUENCY : (Priarity) 2.4GHz/5GHz
AUTHENTICATION : OPEN
ENCRYTION : NONE
ESSID : PRINTER_B03223
DHCP : ENABLED
IP ADDRESS : 192.168.1.1
SUBNET MASK : 255.255.255.0
GATEWAY : 192.168.1.2
PORT : 9100
WLAN MACADDRESS :
0 0 1 5 9 4 B 0 3 2 2 3

BIXOLON SRP-350plusV Specifications

General

Type	POS printer
Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Product color	Black
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 / 60 Hz
Maximum roll diameter	79.5 mm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Mobile operating systems supported	Android, iOS
Windows operating systems supported	Yes
Serial interface	-
Optional connectivity	Bluetooth, Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Internal memory	- MB
Autocutter durability	2 million cuts

Weight and Dimensions

Depth	200 mm
Width	145 mm
Height	146 mm
