1.5 Display Overview
Display Description
Waveform display
Channel status bar
Waveform parameters display
Waveform mode and output impedance indicator
LAN status indicator
Mode phase locked/free running indicator
Menu display
Waveform parameters display
1
2
3
4
5
6
7
8
1
7
3
2
6
5
4
8
