28
2. Select and press the DC waveform softkey from the menu.
3. The cursor position will now be highlighted the first digit of the DC offset parameter
display.
4. Use the rotary knob or the numeric keypad to change the two parameters. Both
parameters can be specified in Vdc or mVdc units.
Configure Arbitrary Waveforms
There are two ways to generate arbitrary waveforms. Users can output a predefined arbitrary
waveform that is built-in, or create and output a user-defined waveform by specifying point by
point arbitrary data using the EasyWave software. Waveforms can be stored in the internal
non-volatile memory. The methods of setting the parameters of an arbitrary waveform signal
are similar to those of the sine waveform function.
Generate Predefined Built-in Waveforms
There are a total of 196 predefined built-in arbitrary waveforms that can output from the
generator. They are divided in the following categories:
