87
2) The slew rate specifications are not warranted but are descriptions of typical performance. The actual transition
time is defined as the time for the input to change from 10% to 90%, or vice versa, of the programmed current
values. In case of very large load changes, e.g. from no load to full load, the actual transition time will be larger
than the expected time. The load will automatically adjust the slew rate to fit within the range (high or low)
that is closest to the programmed value.
Supplementary Characteristics
Memory capacity
100 Groups
Recommended calibration period
Once per year
AC Input (selectable by switch on the rear panel)
Option 1: 220 V ±10%, 50/60 Hz
Option 2: 110 V ±10%, 50/60 Hz
Cooling method
Fan cool
Environmental conditions
This instrument is intended for indoor use in a pollution degree 2 environment. Environmental
limits are as follows:
