34
Display Input On Timer
The instrument has an internal timer that counts how long the input has been enabled (ON).
Follow the steps below to enable the timer display.
1. From the SYSTEM menu, browse and select Displ and press . The following
screen will appear.
2. Select On to enable the timer, and Off (default) to disable. Press to confirm.
3. Press twice to exit the menu. The timer will now be displayed like the following:
4. When input is enabled (ON), the timer will start counting the time. When input is
disabled (OFF), the timer will reset itself to a value close to 0 seconds.
Remote Interface Setup
The instrument has RS232, USBTMC, and GPIB remote interfaces available for remote
communication. Follow the steps below to select and configure each interface.
0.00 W 0.0000 S CC = 1.000A
