81
6 Specifications
Note: All specifications apply to the unit after a temperature stabilization time of 15 minutes
over an ambient temperature range of 23 °C ± 5 °C. Specifications are subject to change
without notice.
Model
8600
8601
8602
Input Ratings
Input Voltage
0 120 V
0 120 V
0 500 V
Input
Current
Low
0 3 A
0 6 A
0 3 A
High
0 30 A
0 60 A
0 15 A
Input Power
150 W
250 W
200 W
Minimum
Operating
Voltage
Low
0.11 V at 3 A
0.18 V at 6 A
1 V at 3 A
High
1.1 V at 30 A
1.1 V at 60 A
4.5 V at 15 A
CV Mode
Range
Low
0 18 V
0 50 V
High
0 120 V
0 500 V
Resolution
Low
1 mV
High
10 mV
Accuracy
Low
±(0.05%+0.02%FS)
±(0.025%+0.05%FS)
±(0.05%+0.025%FS)
High
±(0.05%+0.025%FS)
±(0.025%+0.05%FS)
±(0.05%+0.025%FS)
CC Mode
Range
Low
0 3 A
0 6 A
0 3 A
High
0 30 A
0 60 A
0 15 A
Resolution
Low
0.1 mA
0.1 mA
0.1 mA
High
1 mA
1 mA
1 mA
Accuracy
Low
±(0.05%+0.05%FS)
High
±(0.05%+0.05%FS)
CR Mode
Range
Low
0.05 Ω – 10 Ω
0.3 Ω – 10 Ω
High
10 Ω - 7.5 kΩ
Resolution
16 bit
Accuracy
Low
0.01%+0.08 S
High
0.01%+0.0008 S
CW Mode
Range
150 W
250 W
200 W
Resolution
10 mW
Accuracy
0.1% + 0.1%FS
0.2% + 0.2%FS
0.1% + 0.1%FS
