64
CC
1 A
1
CV
3 V
2
CW
0.5 W
3
CR
2 Ω
4
CC
3.8 A
5
CC
0.5 A
6
CV
2.8 V
7
Refer to section “Save/Recall Instrument Settings” in section “3.3 SYSTEM Menu” for details on
saving settings into internal memory.
Note: If the program requires more than 10 sequences, each program can be linked
(chained) to another program after it has completed.
1. Setup the program parameters. From the front panel press ( ) and then (
) to access the PROGRAM menu. It will look like the display below:
2. Select Edit and press . The first parameter to configure is the Active Sequence.
This allows activating or deactivating a sequence in the program. Sequences that are
activated will be part of the test program. Deactivated sequences will be skipped. To
activate a sequence, press the number corresponding to the sequence using the
numeric keypad. For example, if sequence 1 through 5 are to be activated, press
EDIT PROGRAM
Active Sequence = 0987654321
PROGRAM
Run Recall Edit
