73
3. Enter a value for Voltage On Delay. This can be set between 0.00s and 99.99s. Then
press to continue.
4. Follow the same steps for Current Range. The value must be within the maximum
input limits of the load. Press to continue.
5. Set the Start Current. The value must be less than Current Range. Press to
continue.
6. Do the same for Step Current and End Current. Press after each setting to
continue.
7. Enter a value for OCP Voltage and press to continue.
8. Finally, enter a value for Max Trip Current, and then Min Trip Current. Press
after each settings to continue.
9. The load will prompt to Save OCP File. Select a number between 1 and 5. Then press
to save all settings to the selected location.
Note: At any time when configuring any parameters for the test, you can press the
key to select the previous parameter to edit.
To recall the settings:
1. Press ( ) and to enter the OCP Test menu. Select Recall and
press .
2. Use the keypad or knob to select the saved location number and press .
All settings will be recalled when selecting Edit from the OCP Test menu.
To run the OCP test:
1. Recall the settings from memory by following the steps above.
2. Then, from the OCP Test menu, select Run and press . The display
will show the following:
