BK Precision 9201 - Product Specifications: General, Interface, Environment, Physical; Operating and Storage Conditions; Physical Dimensions and Weight

49
General
Remote Sense
Compensation
1 V
DVM Range
0-60 V
DVM Accuracy
0.02%+10 mV
DVM Resolution
1 mV
Standard
Interface
USB (USBTMC-compliant), GPIB, RS-232
AC Input
110/220 VAC (+/- 10 %), 47 Hz - 63 Hz
Operating
Temperature
32 °F to 104 °F (0 °C to 40 °C)
Storage
Temperature
-4 °F to 158 °F (-20 °C to 70 °C)
Dimensions
(W×H×D)
8.45” x 3.47” x 13.96” (214.5 x 88.2 x
354.6 mm)
8.45” x 3.47” x 17.52” (214.5 x 88.2 x 445
mm)
Weight
16.98 lbs. (7.7 kg)
33.07 lbs. (15 kg)
8 Calibration
We recommend a calibration interval of once per year to ensure that the power supply meets
specifications.
