List Mode Programming Example
If in remote control mode, you can refer to the following example to edit List operation (refer to
MDL Series Programming Guide for more information).
Command Function
LIST:RANGe 40 Sets List range
LIST:COUNT 10000 Sets List cycle
LIST:STEP 2 Sets List steps
LIST:LEVEL 1,5 Sets List step 1 level
LIST:SLEW 1,2 Sets List step 1 slew rate
LIST:WIDTH 1,1 Sets List step 1 width
LIST:LEVEL 2,1 Sets List step 2 level
LIST:SLEW 2,2 Sets List step 2 slew rate
LIST:WIDTH 2,2 Sets List step 2 width
LIST:SAV 2 Saves List to file 2
LIST:RCL 2 Recalls List file 2
FUNCTION:MODE LIST Sets List mode function
TRIG:SOUR BUS Sets trigger source
*TRG Runs List file
Note : This example programs a list on a MDL200 module. For other models, make sure all
range, level, slew, and transient width parameters are within the modules’ specified limits.
