Chapter 1: Specifications
1.3 Network
Network Specifications
Character Count 0 to 65535
Client Connection At power-up or upon data arrival
Connection Modes Server, Client, VCOM, Paired
Delimiters Hex 1 : 01 to FF (begin buffering when hex 1 received);
Hex 2: 01 to FF (send serial data if delimiter hex 2 is set and received)
Diagnostics DIsplay PC IP, ping, text VCOM, save test config (text readable)
Memory Serial: 8 KB per port;
Network memory: 4 KB
Firmware Upgrade Via serial, Ethernet, or auto web search
IP Port Addresses 5300: heartbeat and configuration setting in TCP mode (i.e., Pair mode);
8888: LES424A update
Network
Communications
LAN: 10-/100-Mbps auto-detecting 10BASE-T and 100BASE-TX
Network Physical Layer
Standards
Ethernet: IEEE 802.3 autodetecting and auto MDI/MDI-X 10BASE-T and 100BASE-TX
Protocols Supported TCP, IPv4, UDP, ARP, HTTP 1.0, ICMP/PING, DHCP/BOOTP;
IP mode: Static, DHCP;
TCP/UDP: User-definable;
UDP: Unicast or multicast
Search Serial direct COM and Ethernet autosearch or specific IP
Timeouts Inter-character: 0 to 65535 ms;
Serial: 0 to 65535 ms;
Network: 0 to 65535 min;
Force transmit: 0 to 65535 ms;
Max. character count: 0 to 8192 bytes
