CHAPTER 2: OVERVIEW
TABLE 2-16. STATUS LEDS ON THE ACX080/ACX048 POWER SUPPLY UNIT
NUMBER IN FIGURE 2-12 LED STATUS DESCRIPTION
1 DC Input OK (green)
ON Operating condition
OFF No power supply
DC Input (red)
ON Power supply unit not active. Matrix is powered by second power supply.
OFF Operating condition
