CHAPTER 2: OVERVIEW
POWER SUPPLY UNIT FOR ACX288 AND ACX160
FIGURE 2-11. STATUS LEDS ON THE POWER SUPPLY UNIT
TABLE 2-15. STATUS LEDS ON THE ACX288/ACX160 POWER SUPPLY UNIT
NUMBER IN FIGURE 2-11 LED STATUS DESCRIPTION
1 AC Input OK (green) ON Operating condition
2 DC Output OK (green) OFF Operating condition
3 O/T (yellow)
OFF Normal temperature
ON HIgh temperature
POWER SUPPLY UNIT FOR ACX080 AND ACX048
FIGURE 2-12. STATUS LED ON THE POWER SUPPLY UNIT
