CHAPTER 2: OVERVIEW
FAN TRAY
FIGURE 2-10. STATUS LEDS ON THE PORTS OF THE I/O BOARDS
TABLE 2-13. FAN TRAY LEDS
NUMBER IN FIGURE 2-10 COMPONENT
1 Status LED 1
2 Status LED 2
3 Hot Swap LED
TABLE 2-14. STATUS LEDS ON THE FAN TRAYS
NUMBER IN FIGURE 2-10 LED STATUS DESCRIPTION
1 Status 1 (green) On Operating condition
2 Status 2 (red)
Off Operating condition
On Error indication
3 Hot Swap (blue)
Off Hot Swap option deactivated
On Hot Swap option activated
